Aluminium Stair Nosing - G Series Clear Anodised with TRAKA External Rated Insert

Dear customer, please note: this product variant is manufactured to order with a 2-3 week lead time. The maximum continuous length of this product variant is 2.4m.

 OVERVIEW

• Please note: this product does not conform to AS 1428.1:2021 since it has a 30mm front return. If you require a profile that has been designed in accordance with AS 1428.1:2021, please consider the M Series.

• The G Series is designed for surface-mount/retro-fit installations
• The insert consists of a highly non-slip carborundum grit surface
• The aluminium is CLEAR ANODISED
• Suitable for internal & external environments (for internal stairs, please consider the cleaning method)

• Installed with a combination of adhesive and screws

SPECIFICATIONS

DETAILS

• Designed for surface mount / retro-fit applications on existing stair treads
• Suitable for use on raked, square and bull nosed stair edges
• CLEAR anodised aluminium profile with YELLOW insert provide contrast over a wide range of substrate colours as per AS1428.1 (LRV values available)
• Supplied with TRAKA industrial stair nosing insert intended for extremely high traffic external applications

• Concealed fixings - first the extrusion is fixed to the substrate by way of screws and adhesive and then the self-adhesive insert is fixed to the extrusion
• UV stabilised materials for a long trouble-free service life

• Australian manufactured aluminium extrusion



SCOPE OF SUPPLY

• Anodised aluminium stair nosing extrusion with abrasive insert supplied in lengths
• If 'cut to size' option is selected; aluminium will be supplied cut to the sizes specified in the 'Aluminium Stair Nosing Cutting List' on this page
• If 'pre-drill' option is selected; aluminium will be supplied with countersunk holes pre-drilled at approximately 300mm centres and will also come with the appropriate fixings for the nominated substrate type



OPTIONAL EXTRAS
